Frontenac FP11 Guillotine Door
Dare to design... the fireplace of your dreams, while being environmentally friendly! Frontenac is not only the name of a grand hotel located in the heart of Quebec City, Canada. It is also the largest fireplace of the Valcourt brand.
This price includes the fireplace only. Accessories, venting, chimney, hearth, and installation are available for an additional cost. Call 647-713-0259 or email clickfire.ca@gmail.com for more information.
Majestic and imposing, this bravery symbol of the Count of Frontenac, who has fiercely defended the French colony, is quite appropriate to represent the enormous challenge overtaken when designing and manufacturing this fireplace.
Exceptionally large, the FP11 Frontenac uses advanced technology to reduce air pollution and is already qualifies for Phase II of the US Environmental Protection Agency (EPA) voluntary program for manufacturers of decorative wood burning fireplaces. With particulate emissions below 5.1 g/kg (which is approximately 70 percent cleaner than unqualified models), this model will surely give you elegance without compromising the quality of air.
Just like the FP7-LM Antoinette, the FP11 Frontenac has a guillotine door that disappears in the hearth, allowing you to easily load wood on the fire and have an unrivalled view of the flames.
The fire screen is also equipped with a guillotine mechanism. You will thus enjoy an open fire in safety when the ceramic glass door is open. Finally, the bare front allows significant flexibility and creativity in the design of your interior décor.
GENERAL FEATURES
| Exterior dimension (Depth) | 30 13/16" |
| Fuel type | Dry cordwood |
| Recommended heating area (sq.ft.) | <1,000 |
| Firebox volume (cu. ft.) | 9.4 |
| Burn rate | >5 kg/h (>11 lb/h) |
| Maximum log length | 30" |
| Log positioning | Over width |
| Chimney diameter | 8" |
| Approved for a mobile home installation | No |
| Weight | 920 lb (417 kg) |
| Door type | Guillotine, glass with steel frame |
| Glass type | Ceramic glass |
| Glass surface – dimensions (Width X Height) | 40 3/4" x 23 7/8" |
| Overall dimension (Height) | 74 3/4" |
| Overall dimension (Width) | 59 1/2" |
| Overall dimension (Depth) | 34 1/2" |
| Door opening – dimension (Height) | 27 1/8" |
| Door opening - dimension (Width) | 44 1/2" |
| Firebox – dimension (Height) | 35" |
| Firebox – dimension (Width) | 31 1/4" |
| Firebox – dimension (Depth) | 10 3/4" |
| Centre line of flue outlet to the side | 29 3/4" |
| Centre line of flue outlet to the back | 15 3/8" |
| USA standard (emissions) | ASTM 2515 / ASTM 2558 |
| USA standard (safety) | UL 127 |
| Canadian standard (safety) | ULC-S610 |
| Tested and listed as per applicable standards | By an accredited laboratory (CAN/USA) |
| Warranty | Limited lifetime |
|
Minimum clearances to combustibles * (Data expressed in inches. 1 inch = 25.4 mm) |
||||
| Canada | USA | |||
| Top ** | 84" | 84" | ||
| Shelf | 52" | 52" | ||
|
* The information given on the certification label affixed to the appliance always overrides the information published in any other media (owner's manual, catalogues, flyers, magazines and/or web sites). |
||||
|
** Measured from the platform on which the product is installed. Some appliances have been tested with a low ceiling. If necessary, consult the owner's manual for information on these clearances to combustible materials. |
||||
